The HXS free-standing enclosure pairs a 1.5 mm steel shell with a poured PU seal for IP 55 protection—upgradeable to IP 65 with a roof canopy—giving tall switchgear bays robust dust, water-jet and impact resistance.
Three-point door locking system with toothed mechanism and lever with the option of being equipped with a system or patent insert.
Painted with polyester paint resistant to UV radiation.
As standard, the enclosures are equipped with membrane glands from the top and double aluminum from the bottom.
HXS system standing enclosures of the SOLID GSX series are available in three standard widths (550 mm, 800 mm, 1050 mm) and a depth of 300 mm (enclosure 1850 mm high) and 400 mm (enclosure with a height of 2000 mm). The enclosures have possibility to be equipped with mounting plates, internal sets with electric equipment and a power distribution system based on busbars. Thanks to dedicated mounting holes and weaknesses in the side walls, it is possible to connect the enclosures into sets and carry out wiring or busbars between the sections. Enclosures can be attached to the wall using dedicated openings in the back of the enclosures or brackets intended for that purpose. It is also possible to attach the enclosures to the floor thanks to mounting holes in the plinths.
