Air switch disconnectors are essential components in low-voltage electrical installations, designed to provide safe disconnection of circuits for maintenance, inspection, or emergency shutdowns. They ensure a clear visual break between the power source and the downstream equipment, enhancing the safety of personnel working on de-energized systems.

004696640

Slika EPH-D-40 3H BD/M2C2S2

EPH-D-40 3H BD/M2C2S2 Prekidač za razdvajanje

ETI kod:: 004696640
Primena:: 60947-3
Nazivni impulsni napon Uimp (kV):: 8 kV
Tip konekcije:: Zadnji priključak
Nazivni radni napon (V AC):: 690 V
Broj polova:: 3
Standardi:: 60947-3
Nazivna struja:: 4000 A
Grupa kataloga 1:: ETIPOWER

Proizvod

Težina: 105,93 kg
Stock unit of measure: pcs

Osnovno pakovanje

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838400117144
Basic packaging weight: 106,43 kg
Basic Packaging Dimensions Height: 399 mm
Basic Packaging Dimensions Width: 460 mm
Basic Packaging Dimensions Depth: 368 mm
Basic packaging volume: 67,543 dm³

Transportno pakovanje

Intermediate packaging quantity: 1 pcs
EAN code for a intermediate packaging: 3838400117151
Intermediate packaging weight: 110,93 kg
Intermediate Packaging Dimensions Height: 600 mm
Intermediate Packaging Dimensions Width: 700 mm
Intermediate Packaging Dimensions Depth: 600 mm
Transport packaging quantity: 6 pcs
EAN code for a transport packaging: 3838400117168
Transport packaging weight: 692 kg
Transport Packaging Dimensions Height: 1.750 mm
Transport Packaging Dimensions Width: 1.200 mm
Transport Packaging Dimensions Depth: 840 mm
Transport packaging volume: 1.764 dm³
Pallet quantity: 36 pcs
Customs tariff: 85362090

Motor drive optional: Da
Rated permanent current Iu: 4.000 A
Motor drive integrated: Da
Degree of protection (IP): IP20
Type of control element: Push button
Position of connection for main current circuit: Back side
Type of electrical connection of main circuit: Connection at separate chassis part
Number of poles: 3
Device construction: Built-in device slide-in technique (withdrawable)
With switched-off indicator: Da
Rated voltage(Min): 690 V
Rated voltage(Max): 690 V

ETIM klasifikacija – verzija 9.0
