NH1 gBat 80A/700V DC Topljivi osigurač

ETI kod:: 004723292
Tip osigurača:: NH
Veličina:: NH1
Nazivna struja:: 80 A
Karakteristika:: gBat
Indikator:: Indikator statusa gornjeg osigurača
Nazivni DC napon:: 700 V
DC Prekidna moć:: 30 kA
L/R (ms):: 3 ms
Snaga disipacije (0,7xIn) (W):: 5,4 W
Pd (W):: 12 W
Džulov integral pre el.luka (A2s):: 1.200
Radni Džulov integral (A2s):: 4.800
Standardi:: IEC 60269-7
Primena:: Zaštita baterija

Pribor

Proizvod

EAN code for a single product: 3838895759362
Težina: 490 g
Net width: 46 mm
Net height: 135 mm
Net depth: 61,8 mm
Stock unit of measure: pcs

Osnovno pakovanje

Basic packaging quantity: 3 pcs
EAN code for a basic packaging: 3838895698159
Basic packaging weight: 1,527 kg
Basic Packaging Dimensions Height: 0,069 m
Basic Packaging Dimensions Width: 0,146 m
Basic Packaging Dimensions Depth: 0,138 m
Basic packaging volume: 0,001 m³

Transportno pakovanje

Transport packaging quantity: 24 pcs
EAN code for a transport packaging: 3838895698166
Transport packaging weight: 12,567 kg
Transport Packaging Dimensions Height: 0,255 m
Transport Packaging Dimensions Width: 0,295 m
Transport Packaging Dimensions Depth: 0,235 m
Transport packaging volume: 0,018 m³
Pallet quantity: 1.248 pcs
Customs tariff: 85361090

Voltage type: DC
Fuse construction type according to IEC 60269: NH1
Power loss at rated current: 12 W
Rated switching capacity DC: 30 kA
Type of fuse status indicator: Top fuse status indicator
Rated current: 80 A
Rated voltage DC: 700
Utilization category: Other
