MOD. M T2 PV 125/20 Odvodnik prenapona

ETI kod:: 002440734
Funkcija:: SPD Modul
Sistem uzemljenja:: PV
Grupa kataloga 1:: ETITEC M PV
Instalacija:: PV zaštita
IP zaštita:: IP20
Struja curenja:: Yes
Primenjena tehnologija:: MOV
Tip odvodnika prenapona:: T2
DC maks. trajni radni napon Uc:: 125 V
Za upotrebu sa:: ETITEC M T2 PV
Tip struje:: DC
In (8/20):: 20 kA

Proizvod

Težina: 0,05 kg
Net width: 18 mm
Net height: 45 mm
Net depth: 64,14 mm
Stock unit of measure: pcs

Osnovno pakovanje

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895966258
Basic packaging weight: 0,06 kg
Basic Packaging Dimensions Height: 72 mm
Basic Packaging Dimensions Width: 24 mm
Basic Packaging Dimensions Depth: 50 mm
Basic packaging volume: 0,086 dm³

Transportno pakovanje

Transport packaging quantity: 24 pcs
EAN code for a transport packaging: 3838895966265
Transport packaging weight: 1,521 kg
Transport Packaging Dimensions Height: 83 mm
Transport Packaging Dimensions Width: 305 mm
Transport Packaging Dimensions Depth: 116 mm
Transport packaging volume: 2,937 dm³
Pallet quantity: 8.160 pcs
Customs tariff: 85363090

Max. discharge surge current (8/20): 50 kA
Max. continuous voltage DC: 125 V
Degree of protection (IP): IP20
Mounting method: On basic element
Construction size: 1 modular spacing
Short-circuit breaking capacity (Isccr): 11 kA
Signalling at the device: Optical
Category type 2: Da
Nominal discharge surge current (8/20): 20 kA
System configuration DC: Da

ETIM klasifikacija – verzija 9.0
