Automatski prekidač ETIMAT P10 1p+N C6 15kA 001901627

Specifikacije

Šifra proizvoda:
001901627
Opis:
ETIMAT P10 1p+N C6 15kA
Ime razreda:
Automatski prekidač
Nazivna struja:
6
Karakteristika okidanja:
C
Broj polova:
1+N
Nazivna prekidna moć:
15
Tip napona:
AC
Nazivni napon:
240
Nazivna frekvencija (Hz):
50...60
Nazivni impulsni napon Uimp (kV):
6
nazivni poprečni presek:
1...25
Standardi:
EN/IEC 60898-1; EN/IEC 60947-2
Funkcija:
MCB

Dokumenti

Proizvod

Etikod EAN
3838400135759
Eticode težina
0.184  kg
Carinska tarifa
85362010
logis_net_width
91  mm
logis_net_height
79  mm
logis_net_depth
220  mm

Osnovno pakovanje

Količina
6
EAN
3838400135766
Težina
1.16  kg

Transportno pakovanje

Količina
54
EAN
3838400135773
Težina
10.79  kg
Broj paleta
2808
Klasifikacija
EC000042
Ime razreda
Miniature circuit breaker (MCB)
Release characteristic
C
Number of poles (total)
2
Number of protected poles
1
Rated current
6A
Rated voltage
240V
Rated insulation voltage Ui
500V
Rated impulse withstand voltage Uimp
6kV
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
15kA
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
15kA
Voltage type
AC
Frequency
50…60Hz
Current limiting class
3
Suitable for flush-mounted installation
Da
Concurrently switching neutral conductor
Da
Over voltage category
3
Pollution degree
2
Additional equipment possible
Da
Width in number of modular spacings
2
Built-in depth
70mm
Degree of protection (IP)
IP20
Ambient temperature during operating
-60…70°C
Connectable conductor cross section multi-wired
1…25mm²
Connectable conductor cross section solid-core
1…25mm²
ETIM Clasifikacija – Verzija
001901627 Kućište Miniature circuit breaker, ETIMAT P10 1p+N C6 15kA ASTI MCB ETIMAT P10 15kA Normal 1p+N C Modularni zaštitni uređaji Minijaturni automatski prekidač MCB i pribor Minijaturni automatski prekidač MCB ETIMAT P10 1P+N Funkcija MCB Nazivna prekidna moć 15kA Karakteristika okidanja C Nazivna struja 6A Nazivni napon 240V Broj polova 1+N Nazivna frekvencija 50...60Hz Standardi EN IEC 60898-1; EN IEC 60947-2 nazivni poprečni presek 1...25 Tip napona AC Nazivni impulsni napon Uimp 6kV Terminali 1...25 ETIMAT MCB 6 C 1+N 15 AC 240
Miniature circuit breaker, ETIMAT P10 1p+N C6 15kA, Rated current (A) 6, Function MCB, Number of poles 1+N, Rated voltage (V) 240, Rated cross section 1...25, Rated Frequency (Hz) 50...60, Rated impulse withstand voltage Uimp (kV) 6, Short circuit capacity (kA) 15, Standards EN/IEC 60898-1,logis_long_descr= EN/IEC 60947-2, Tripping characteristic C, Voltage type AC, Release characteristic C , Number of poles (total) 2 , Number of protected poles 1 , Rated current 6 A, Rated voltage 240 V, Rated insulation voltage Ui 500 V, Rated impulse withstand voltage Uimp 6 kV, Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V 10 kA, Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V 10 kA, Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V 15 kA, Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V 15 kA, Voltage type AC , Type of drive 50…60 Hz, Current limiting class 3 , Suitable for flush-mounted installation TRUE , Concurrently switching neutral conductor TRUE , Over voltage category 3 , Pollution degree 2 , Additional equipment possible TRUE , Width in number of modular spacings 2 , Built-in depth 70 mm, Degree of protection (IP) IP20 , Ambient temperature during operating -60…70 °C, Connectable conductor cross section multi-wired 1…25 mm², Connectable conductor cross section solid-core 1…25 mm²
